Single-soldier FPV drone handheld portable full-frequency wireless detector with a range of 70 MHz-6.2 GHz.

Single-soldier FPV drone handheld portable full-frequency wireless detector with a range of 70 MHz-6.2 GHz.

Identification types:
Supports customizable scanning from 70 MHz to 6.2 GHz.
Default detection bands: 400 MHz, 800 MHz, 900 MHz, 1.2 GHz, 1.4 GHz, 2.4 GHz, 5.2 GHz, 5.8 GHz (other bands can be customized)
Detection radius:
≥ 1.5 km (line-of-sight, clean electromagnetic environment).
$1570

China UAV detection equipment Manufacturers, Suppliers, Factory

HLXTONG is a manufacturer, supplier and wholesaler of signal drone detection,We can provide professional service and better price to you. If you are interested in our products, welcome to contact us.

What are the characteristics of the HLXTONG drone detector?

The HLXTONG drone detector is made of pure aluminum material, which has better heat dissipation effect; sufficient power, stable performance; small current soft control switch signal line; built-in VCO,It has a zigzag shape and a triangular waveform high-efficiency scanning; This drone detector is designed to generate a strong radio frequency signal that interferes with the drone’s communication system, effectively disabling it.customers can customize the frequency according to their needs.

What is the use of the HLXTONG drone detector?

All of our jammer products require the HLXTONG drone detector, which is an important part of all jammer products.HLXTONG drone detector can shield 2G, 3G, 4G, 5G, WIFI, GPS and other signals in various frequency bands.

What frequencies can the HLXTONG signal jammer customize?

HLXTONG drone detector Customized Frequency

Device Technical Parameters

Name	Specifications
Identification types	Supports mainstream drones such as DJI, Autel, Hubsan, as well as FPV racing drones and DIY drones
Frequency range	Supports customizable scanning from 70 MHz to 6.2 GHz. Default detection bands: 400 MHz, 800 MHz, 900 MHz, 1.2 GHz, 1.4 GHz, 2.4 GHz, 5.2 GHz, 5.8 GHz (other bands can be customized)
FPV video transmission detection	Supports detection of all analog video transmissions within the 500 MHz–6 GHz frequency range (user-customizable)
Detection radius	≥ 1.5 km (line-of-sight, clean electromagnetic environment).
Video capture distance	≥ 1.5 km (line-of-sight, clean electromagnetic environment).
Video storage capacity	32 GB memory card
Detection response time	≤3s（8 bands）；≤5s（12 bands）
Alarm modes	Sound, vibration, and light
Screen size	7-inch touchscreen
Power supply	Powered by lithium battery
Battery capacity	7000mAh
Device weight	≤2kg
Device size	Length × Width × Height： 200mm×130mm×40mm

. Device Features and Functions

Full-band detection: Capable of detecting the entire 70 MHz–6.2 GHz range.
Comprehensive FPV band coverage: Fully supports analog video transmission detection within

the 500 MHz–6 GHz range.
